EN
6
AR6410/AR6410L User Guide
The AR6410/AR6410L 6-channel ultra micro receiver with integrated servos, speed
control and X-Port ™ technology is designed for ultra micro aircraft. Featuring
DSM2 ™ /DSMX ® technology, the AR6410/AR6410L is compatible with all Spekt-
rum ™ , JR ® , E-flite ® and ParkZone ® 2.4GHz DSM2/DSMX technology transmitters.
NOTICE: The AR6410/AR6410L receiver is not compatible with the DX6 park flyer
radio system.
Features
• 6-channel ultra micro receiver
• Two integrated linear servos (elevator and rudder)
• Integrated brushed speed control
• Compatible with external brushless speed controls (optional)
• Weighs just 3.9 grams
• Compatible with optional Spektrum ultra micro linear servos
• Smart Bind ™ technology
• X-Port allows for future expansion
Applications
The AR6410/AR6410L is designed for ultra micro aircraft and is ideal for scratc-
-built ultra micro projects. The AR6410/AR6410L is designed to use a single cell
LiPo battery. Two sizes are available, 3.7V 110mAh (EFLB1101S/PKZ1034) and
3.7V 70mAh (PKZ3001). The integrated brushed speed controller can be used to
power a brushed motor drawing up to 2 amps of continuous current or an optional
brushless speed controller can be used. An integrated X-Port feature allows for
future expansion.
When X-Port is active, CH5 and CH6 are not available; however, reversed aileron
(CH2) is still available.
Specifications:
AR6410/AR6410L
Type: DSM2/DSMX ultra micro receiver with integrated brushed speed
controller and two linear servos
Channels: 6 channels or 4 channels, plus X-Port
Modulation: DSM2/DSMX
Dimension (WxLxH): 27.75 x 27.15 x 8.10mm
Weight: 3.9 g
Input Voltage Range: 1-cell LiPo 3.2 to 4.2V
Antenna Length: 31mm
Resolution: DSM2/DSMX 1024
Compatibility: All DSM2/DSMX aircraft transmitters
Servos:
Force: 2.8 oz (79 g)
Stroke: AR6410–7.4mm, AR6410L–9.1mm
Speed: 0.14 sec
Speed Controller:
Type: Integrated brushed
Max continuous current: 2.0 amps
