Located on the left-hand side of the transmitter is the charging jack, which accepts only JR®
or Spektrum style wall chargers. Please do not attempt to use any other brand of wall charger
as it may be reverse polarity and can cause damage to your system. Only use the JR or
Spektrum
type wall charger when the DX3.0 is equipped with Ni-Cd batteries.
Spektrum Transmitter Charge Jack Polarity:
n
Charging Jack
Charger Pigtail For Transmitter
Black To Positive
Red To Negative
