Lap Timer

The Lap Timer function of the DX3.0 allows the recording of individual lap times based on a

999 second up-timer. Up to 50 laps and times from 3.0 to 99.9 seconds can be stored in

memory for review at a later time. The Lap Timer function will only be enabled and shown in

Function mode if Grip Button C (System Mode) is set to “LA.” With the Lap Timer enabled,

pressing the channel key will alternate between the Normal display screen and Up-Timer

display screen.

The Lap Timer is started by pressing Grip Button C. Once active, as shown by the blinking word

“LAP,” pressing Grip Button C again will begin recording the time of the next lap.

Note: A 3.0-second lap is the quickest lap allowed. This prevents accidental double pushing of

Grip Button C when recording lap times. If more than 50 laps are recorded, each new lap will

overwrite the oldest lap held in memory.

To stop the Lap Timer, press the Increase and Decrease keys at the same time. To restart the Lap

Timer, press Grip Button C. To reset the Up-Timer, press the Channel key to show the Up-Timer

display screen. With the Up-Timer stopped, press the Increase and Decrease keys at the same

time to reset.

To review or reset lap times you must be in the Lap Timer function mode screen. Upon entering

this function, the screen will always show the last lap time recorded. Use the

Increase or Decrease keys to view the desired lap(s).

Note: If a recorded lap time is greater than 99.9 seconds, “OVR” will be displayed.

To clear all lap times, press the Increase and Decrease keys at the same time.

Accessing the lap Timer Function

1. Turn the transmitter power switch on.
2. Press the

SCROLL key to access Function mode.

3. Press the

SCROLL key until LAP appears in the screen.

4. Press the

INCREASE or DECREASE key to view the desired lap time(s).

5. To reset all lap times, press the

INCREASE and DECREASE keys at the same time.

6. Press the

SCROLL key to access the Sub-Trim function.

7. To exit the Function mode, either turn the transmitter power switch off or press the

SCROLL and CHANNEL keys at the same time.

40I

L A P

–

Recorded Lap Time to 1/10th of a second
(e.g., 40.1 sec.)

Current Lap Number

Function Mode

Programmable

Mixing

–

The DX3.0 offers two different mixing adjustments that allow for mixing one channel to another

channel. The mixes available are Steering-to-Auxiliary Channel Mixing and Throttle-to-Auxiliary

Channel Mixing. Each direction is independently adjustable. Popular use of this function

includes 4-wheel steering and independent front and rear wheel brakes.

For example, Throttle-to-Auxiliary channel mixing can be used for independent front and rear

wheel brakes. Each time the throttle/brakes are moved, the auxiliary channel will move in the

direction and to the value input being given by the throttle channel. Mixing is proportional, so

small inputs to the throttle will result in small output from the auxiliary

channel. The adjustment range is from -125% to 0% to 125%. If the rate is negative, the

channel is mixed in the opposite direction.

Both mixes share a single mixing “offset.” The purpose of the mixing offset is to redefine the

neutral position of the auxiliary channel, which can be set using Grip Lever A when

“LN” is selected in the Auxiliary Channel 3 function. If the “LN” selection is turned off in the

Auxiliary Channel 3 function with an offset value currently present, the value will

continue to act as a mixing offset until the value is either cleared or changed. If a mix is not

required, it is strongly suggested the mixing rate be set for 0%, which is the default.

Accessing the mixing Adjustment Function

1. Turn the transmitter power switch on.
2. Press the

SCROLL key to access Function mode.

3. Press the

SCROLL key until MIX appears in the screen.

4. Press the

CHANNEL key to select the desired mix to be used.

5. Move the steering wheel or trigger in the desired direction for adjustment (left/right,

forward/reverse or brake). Press the

INCREASE or DECREASE key to achieve the

desired amount of mixing. Move the wheel or trigger in the opposite direction to adjust

the mixing in the opposite direction.

Note: For Auxiliary Channel 3 function, if LN is selected, only L/F is adjustable.
6. Press the

SCROLL key to access the Lap Timer (if enabled) or Sub-Trim function.

7. To exit the Function mode, either turn the transmitter power switch off or press the

SCROLL and CHANNEL keys at the same time.

M I X

THB

M I X

STL

–
