AT-MCF106xx and AT-MCF112xx Installation Guide

13

"

Check the attenuation on the fiber optic cabling after installation.
Refer to Table 4 for the maximum allowable loss budget.

Table 4 Maximum Allowable Loss Budget

Checking the Multichannel Media Converter Package

Your media converter package should include the following items:

"

One AT-MCF106xx or AT-MCF112xx Multichannel Media Converter

"

Rack mounting kit

"

One AC power cord

"

Four self-adhesive rubber feet

"

This installation guide

"

Warranty card

If any of the above items are missing or damaged, contact your Allied Telesyn
representative.

Model

Maximum Allowable Loss
Budget

Wavelength

AT-MCF106ST

20 dB (MMF)

1310 nm

AT-MCF106SC

20 dB (MMF)

1310 nm

AT-MCF106MT

20 dB (MMF)

1310 nm

AT-MCF106VF

20 dB (MMF)

1310 nm

AT-MCF106SM

13 dB (SMF)

1310 nm

AT-MCF106LH

25 dB (SMF)

1310 nm

AT-MCF112ST

20 dB (MMF)

1310 nm

AT-MCF112SC

20 dB (MMF)

1310 nm

AT-MCF112MT

20 dB (MMF)

1310 nm

AT-MCF112VF

20 dB (MMF)

1310 nm

AT-MCF112SM

13 dB (SMF)

1310 nm

AT-MCF112LH

25 dB (SMF)

1310 nm
