20
Fiber Optic Port Specifications
Table 6 through Table 9 lists the specifications for the 10Base-F fiber optic
port.
Table 6 Fiber Optic Transmitter
Table 7 Fiber Optic Receiver
Table 8 Fiber Optic Datalink
Model
Fiber
Type
1
1. MMF = Multimode Fiber.
Fiber
Optic
Diameter
Optical
Frequency
Launch Power (dBm) 2
2. The launch power is measured at one meter from the transmitter.
Maximum Average Minimum
All Models MMF 62.5/125
microns 850 nm -12.0 -15.0 -18.0
Model
Fiber
Type
1
1. MMF = Multimode Fiber.
Fiber
Optic
Diameter
Optical
Frequency
Receiver Power (dBm)
Maximum Average Minimum
All Models MMF 62.5/125
microns 850 nm -12.0 -32.5 -34.0
Model
Fiber
Type
1
1. MMF = Multimode Fiber.
Fiber
Optic
Diameter
Optical
Frequency
Minimum
Power/
Link
Budget
Average
Signal
Loss Maximum
Distance
Spec
2
2. Half-duplex only.
All Models MMF 62.5/125
microns 850 nm 13.0 dB 18.7 dB 2 km
(1.2 mi)
