2
Table 1 lists the maximum operating distances for the AT-MC13 and AT-MC14
media converters.
Table 1 Maximum Operating Distances
Key Features
The media converters have the following key features:
q
Twisted pair port with an RJ-45 connector
q
Fiber optic port with a ST or SC connector
q
LEDs for unit and port status
q
Half- or full-duplex mode operation
q
MissingLink

notifies end-nodes of link failures
q
NML/LNK TST button that performs a link test on the media
converter
q
MDI/MDI-X switch that eliminates the need for a crossover cable
q
External AC/DC power adapter
q
Standard size for desktop use or in an AT-MCR12 rackmount chassis
Twisted Pair Port
The 10Base-T port on the AT-MC13 and AT-MC14 media converters have an
RJ-45 connector and is designed to operate with Category 5 or better shielded
twisted pair cable.
Model
10Base-F 10Base-T
Connector
Maximum Operating
Distance
1
1. Maximum operating distance may be less depending on the duplex mode of the end-nodes and the type of fiber
optic cabling used with the port.
Connector
Maximum Operating
Distance
AT-MC13 ST 2 km (1.2 mi) RJ-45 100 m (328 ft)
AT-MC14 SC 2 km (1.2 mi) RJ-45 100 m (328 ft)
