18
Technical Specifications
Table 6 lists the technical specifications for the media converter.
Table 6 Technical Specifications
Table 7 and Table 8 list the technical specifications for the fiber optic port
using either 50/125 or 62.5/125 micron multimode fiber optic cable.
Specifications
Dimensions (W x D x H) 4.125 in x 3.75 in x 1.0 in
(10.5 cm x 9.5 cm x 2.5 cm)
Maximum Operating Temperature 0° C to 40° C (32° F to 104° F)
Maximum Storage Temperature -20° C to 80° C (-4° F to 176° F)
Operating Altitude up to 3,048 m (10,000 ft)
Humidity 5% to 80% (non-condensing)
EMI/RFI meets FCC Class A, EN55022 Class A
Safety EN60825
EN60950
Immunity EN50082-1 Immunity Standard
Power:
Input Supply Voltage
Maximum Current
Power Consumption 12 V DC
±
5%
500 mA
6 W
Table 7 Fiber Optic Port Launch Power and Receive Power
Cable
Type
Launch Power (dBm) Receive Power (dBm)
Max. Avg. Min.
Minimum
Sensitivity Typical
Sensitivity
Saturation
50/125
micron -14.0 -20.3 -22.5 -31.8 -34.5 -14.0
62.5/125
micron -14.0 -16.8 -19.0 -31.8 -34.5 -14.0
