OmniConnect ISDN Quick Install Guide
3
Topology
Plan your topology including the OmniConnect. The sample topology below
shows the ISDN OmniConnect used for a group of PC users in a small office
network. In this example, four 10 Mbps PC NICs and a telephone are connected
to the OmniConnect.
*Note: Port 1 is either a Workstation or LAN
Legend
ISDN Cable (RJ-45)
10Base-T Cable
Line
10 Mbps Workstations
ISDN (U)
OmniConnect*
ISDN
Telephone Cable (RJ-11)
1 2 3 4
(NT-1 for S/T)
or (S/T)
Phone or FAX
