14
Single-mode Port Specifications
Table 6 Fiber Optic Transmitter
Table 7 Fiber Optic Receiver
Model
Fiber
Type
1
1. SMF = Single-mode Fiber
Fiber Optic
Diameter
(microns)
Optical
Frequency
Launch Power (dBm)
2
2. The launch power measured at one meter from the transmitter
Max. Avg. Min.
AT-MC104XL SMF 9/125 1310 nm -8.0 -11.5 -15.0
AT-MC104LH SMF 9/125 1310 nm 0.0 -3.0 -5.0
AT-MC104SC/FS3
and
AT-MC104ST/FS3 SMF 9/125 1310 nm 0.0 -2.0 -4.0
AT-MC104SC/FS4
and
AT-MC104ST/FS4 SMF 9/125 1550 nm 0.0 -1.5 -3.0
Model
Fiber
Type
1
1. SMF = Single-mode Fiber
Fiber
Optic
Diameter
(microns)
Optical
Frequency
Receive Power (dBm)
Min. Typical Saturation
AT-MC104XL SMF 9/125 1310 nm -31.0 -31.0 -8.0
AT-MC104LH SMF 9/125 1310 nm -35.0 -38.0 0.0
AT-MC104SC/FS3
and
AT-MC104ST/FS3 SMF 9/125 1310 nm -37.0 -37.0 -3.0
AT-MC104SC/FS4
and
AT-MC104ST/FS4 SMF 9/125 1550 nm -37.0 -37.0 -3.0
