Uplink configuration – Allied Telesis AT-FS708 CentreCOM User Manual
Page 23
AT-FS708 and AT-FS708E Installation Guide
13
Uplink Configuration
For 100 Mbps connection to the backbone, use Port 8 MDI. Figure 6 illustrates
how the AT-FS708 switches can be used as an uplink to the backbone in a
typical office complex using Category 5 UTP cable.
Figure 6 Switches as Uplink to the Backbone
X To
PC
=
To
HUB
X To
PC
=
To
HUB
X To
PC
=
To
HUB
CORPORATE BACKBONE
AT-FS708 Switch
AT-FS708 Switch
AT-FS708 Switch
FORMULA 8200 Switch
Sales
Engineering
Finance
MIS
SNMP Station
Hub
Hub
Hub
