Product Description
2
Common Major Features
These switches come with the following common features:
❑
IEEE 802.3 and IEEE 802.3u compliant
❑
RJ-45 ports that can be connected/disconnected without powering off
the switch
❑
Store and forward switching at full-wire speed (14,880 packets per
second on 10 Mbps ports and 148,880 packets per second on 100 Mbps
ports)
❑
Media-dependent interface (MDI) on Port 8 MDI for hub connection or
Port 8 MDI-X for PC connection
❑
Support for up to 17K MAC addresses
❑
Internal power supply (100-240 VAC) for AT-FS708, or external power
adapter for AT-FS708E
❑
Desktop or wall-mount
The switch models described in this guide complement the other Allied
Telesyn Fast Ethernet products, providing simple, cost-effective solutions for
switching between 10 and 100 Mbps. Easy to install, simply connect your
10Base-T or 100Base-TX station ports, and plug in the power.
Figure 1 and Figure 2 show the front panels of the switches.
Figure 1 AT-FS708 Front Panel
Figure 2 AT-FS708E Front Panel
X To
PC
=
To
HUB
X To
PC
=
To
HUB
