AT-MR904TX Hub
7
Note
If you connect to Port 1 on the second hub, make sure that the
MDI/MDI-X switch for Port 1 is set to the MDI-X position. Ports 2
through 4 of the second hub are internally set to MDI-X.
Figure 5: Cascading Hubs
+9 ~ 12VDC
STACK ID MDI-X
4X 3X 2X 1
MDI
1 2
+9 ~ 12VDC
STACK ID MDI-X
4X 3X 2X 1
MDI
1 2
+9 ~ 12VDC
STACK ID MDI-X
4X 3X 2X 1
MDI
1 2
+9 ~ 12VDC
STACK ID MDI-X
4X 3X 2X 1
MDI
1 2
