Installation 22 – Allied Telesis AT-GS924GB User Manual
Page 34
Installation
22
2. If you installed optional fiber optic GBIC modules, remove the dust
covers from the ports.
Figure 12 Removing the Dust Covers from the Fiber Optic Ports
Caution
Do not remove the dust covers if you do not intend to connect the
fiber optic cables at this time. Dust contamination can adversely
impact the operations of the ports.
3. Attach the fiber optic data cables to the fiber optic ports.
Figure 13 Attaching a Fiber Optic Cable
CLASS 1
LA
SER
PR
ODU
CT
DO
NO
T ST
ARE
INT
O BEAM
7
GB
IC
GB
IC
CLASS 1
LA
SER PR
ODUCT
DO NO
T ST
ARE
INT
O BEAM
7
GBIC
GBIC
