AT-GS924GB Gigabit Ethernet Switch Installation Guide
3
Components
Figure 1 illustrates the front panel of the AT-GS924GB switch.
Figure 1 Front Panel of the AT-GS924GB switch
Figure 2 illustrates the back panel of the AT-GS924GB switch.
Figure 2 Back Panel of the AT-GS924GB switch
10/100/1000Base Twisted Pair Ports Port LEDs
AT-GS924GB
10/100/1000Base-T Gigabit Ethernet Switch with GBIC Uplinks
CLASS 1 LASER PRODUCT DO NOT STARE INTO BEAM
1 3 5 7 9 11 13 15 17 19 21 23
2 4 6 8 10 12 14 16 18 20 22 24
GBIC GBIC
23 24
GBIC Expansion Slots
AC Power Connector
100-240 VAC
