Allied Telesyn
AT-VIEW PLUS
VLAN MANAGER
6.9 AT-9800/SwitchBlade Series
Topics:
•
•
6.9.1 VLAN Information Window
The VLAN Information Window displays the following attributes for each VLAN definition:
Column Name
Description
Name
This is the name of the VLAN.
Identifier
This is the unique identifier of the VLAN.
Tagged Ports
This is a list of the tagged member ports of the VLAN.
Untagged Ports
This is a list of the untagged member ports of the VLAN.
Type
This indicates the status of the VLAN.
•
Port-based
•
IP subnet-based
•
Protocol-based
•
MAC address-based
•
Limited protocol-based
Status
This indicates the status of the VLAN.
•
dynamic
•
static
Note
- After an Import VLAN operation, the default VLAN definition will have a failed status if one
of its ports is not associated with any other VLAN definitions. This is caused by the way the Import
VLAN operation works. The Import VLAN operation deletes the existing VLAN configuration on
the target device. Afterwards, VLAN Manager adds the VLAN definitions from the VLAN
Definition File in a sequential manner, starting with the Default VLAN definition. The problem will
occur if the VLAN Definition File contains VLAN definitions (other than the Default VLAN) that
have untagged ports. When the default VLAN definition with the missing untagged ports is added,
the target device will return an error since there are no existing VLAN definitions that have the
missing untagged ports.
PN 613-50595-00 Rev B
Page 45 of 48
