Allied Telesyn AT-VIEW PLUS
VLAN MANAGER
Write Community
This is the community string to use in performing SNMP SET operations on the target host. By
default, this field is set to private.
Login
User Name
This is the account name to be used to log in to the device. By default, this field is set to manager.
This field is used for non-L2 devices only. For L2 devices, this field is ignored.
Password
This is the password for the account to be used. This field is used for non-L2 devices only. For L2
devices, this field is ignored.
Retry
Timeout
The number of seconds VLAN Manager waits before it determines that the device is not responding.
By default, this value is set to 5 seconds.
Count
The number of times VLAN Manager sends SNMP messages to the agent before giving up. By
default, this value is set to 2 retries.
5.1.2 Close
This option closes the active connection with the device and empties the VLAN Information
Window.
5.1.3 Properties
The Properties dialog box allows you to modify the connection settings for the connected device.
The Properties dialog box is identical to the Open dialog box used to open a connection. See
Section
5.1.1 - Open .
Note - This option is only available if VLAN Manager is already connected to a target host.
PN 613-50595-00 Rev B Page 17 of 48
