Allied Telesyn
AT-VIEW PLUS
VLAN MANAGER
6.5 AT-8300GB Series
Topics:
•
•
6.5.1 VLAN Information Window
The VLAN Information Window displays the following attributes for each VLAN definition:
Column Name
Description
Name
This is the name of the VLAN.
Identifier
This is the unique identifier of the VLAN.
This is a list of the tagged member ports of the VLAN that belong to a
specific module on the stack.
This is a list of the untagged member ports of the VLAN that belong
to a specific module on the stack.
Status
This indicates the status of the VLAN.
•
idle
•
operational
•
under-construction
•
not-operational
Note
- Ports in the Default VLAN cannot be changed from untagged to tagged.
Note
- VLAN definitions that contain tagged ports cannot be deleted.
Note
- VLAN definitions that contain tagged ports cannot be deleted during an Import VLAN
operation.
Note
- The retry timeout must be set to a higher value when adding or modifying VLAN definitions.
The timeout value varies depending on the number of devices in the stack.
6.5.2 Add/Modify VLAN Dialogs
The Add/Modify VLAN Dialogs display the following Input Fields:
PN 613-50595-00 Rev B
Page 37 of 48
