Allied Telesyn AT-VIEW PLUS
VLAN MANAGER
6.13 AT-RG600 Series
Topics:
• VLAN Information Window
• Add/Modify VLAN Dialogs
6.13.1 VLAN Information Window
The VLAN Information Window displays the following attributes for each VLAN definition:
Column Name Description
Name This is the name of the VLAN.
Identifier This is the unique identifier of the VLAN.
Tagged Ports This is a list of the tagged member ports of the VLAN.
Untagged Ports This is a list of the untagged member ports of the VLAN.
Priority This indicates the 802.1p Priority.
Status
This indicates the status of the VLAN.
• dynamic
• static
Note - VLANs whose names start with a number cannot be deleted.
PN 613-50666-00 Rev B Page 55 of 56
