Allied Telesyn
AT-VIEW PLUS
VLAN MANAGER
6.11 AT-8900 Series
Topics:
•
VLAN Information Window
•
Add/Modify VLAN Dialogs
6.11.1 VLAN Information Window
The VLAN Information Window displays the following attributes for each VLAN definition:
Column Name
Description
Name
This is the name of the VLAN.
Identifier
This is the unique identifier of the VLAN.
Operation Mode
This indicates the operation mode of the VLAN.
Type
This indicates the type of the VLAN.
•
Port-based
•
Multiple Type
Tagged Ports
This is a list of the tagged member ports of the VLAN.
Untagged Ports
This is a list of the untagged member ports of the VLAN.
Uplink Ports
This is a list of the uplink ports of the VLAN.
Private Ports
This is a list of the private ports of the VLAN.
Core Ports
This is a list of the core ports of the VLAN.
Customer Ports
This is a list of the customer ports of the VLAN.
Status
This indicates the status of the VLAN.
•
dynamic
•
static
Note
- When a port that was already associated to a Normal or Private VLAN was added on a
Nested VLAN, an error message will not be displayed though the operation is not successful.
Note
- When performing a Modify VLAN operation on a Nested VLAN, ports with status that
are the same with the associated port to a Normal or Private VLAN will not be successfully
added including the ports that are already on the VLAN before the operation.
Note
- After an Import VLAN operation, the Default VLAN with invalid Untagged Ports will
have a successful status.
Note
- For the Import VLAN operation:
PN 613-50666-00 Rev B
Page 51 of 56
