Allied Telesyn AT-VIEW PLUS
VLAN MANAGER
Authentication Password
If the Security Level is "Auth / No Priv" or " Auth / Priv", you need to specify an
Authentication Password that is configured for the User Account Name on the
target device.
Privacy Protocol
If the Security Level is "Auth / Priv", you need to specify a Privacy Protocol. This
is the available Privacy Protocol:
DES
Use Data Encryption Standard
Privacy Password
If the Security Level is "Auth / Priv", you need to specify a Privacy Password that
is configured for the User Account Name on the target device.
Login
User Name
This is the account name to be used to log in to the device. By default, this
field is set to manager. This field is used for non-L2 devices only. For L2
devices, this field is ignored.
Password
This is the password for the account to be used. This field is used for non-
L2 devices only. For L2 devices, this field is ignored.
Retry
Timeout
The number of seconds VLAN Manager waits before it determines that the
device is not responding. By default, this value is set to 5 seconds.
Count
The number of times VLAN Manager sends SNMP messages to the agent
before giving up. By default, this value is set to 2 retries.
5.1.2 Close
This option closes the active connection with the device and empties the VLAN Information
Window.
5.1.3 Properties
The Properties dialog box allows you to modify the connection settings for the connected device.
The Properties dialog box is identical to the Open dialog box used to open a connection. See
Section 5.1.1 - Open .
Note - This option is only available if VLAN Manager is already connected to a target host.
PN 613-50666-00 Rev B Page 19 of 56
