Installation
56
Installing an Optional GBIC Module
For the
AT-8550GB
To install an optional GBIC module in an AT-8550GB Switch, perform the
following procedure:
Note
A GBIC module can be hot-swapped; you do not have to power off
a switch to install it.
1. Unpack the GBIC module from its shipping container and store the
packaging material in a safe location.
Note
You must use the original shipping material if you need to return
the module to Allied Telesyn.
Warning
A GBIC module can be damaged by static electricity. Be sure to
observe all standard electrostatic discharge (ESD) precautions, such
as wearing an antistatic wrist strap, to avoid damaging the module.
2. Check that the GBIC package includes all the items listed below. If
any item is missing or damaged, contact your Allied Telesyn sales
representative for assistance.
❑
One GBIC module
❑
Installation Guide
❑
Warranty card
Note
For fiber optic cabling specifications, refer to the GBIC Installation
Guide provided with your module.
3. Follow these guidelines to ensure proper performance of your
GBIC:
❑
GBICs are static sensitive. To prevent Electrostatic Discharge
(ESD) damage, follow your normal board and component
handling procedures.
❑
GBICs are dust sensitive. When the GBIC is stored or when a
fiber-optic cable is not plugged in, always keep plugs in the
GBIC optical bores.
