AT-8500 Series Fast Ethernet Switch Installation Guide
53
Installing an Optional Expansion or Stacking Module
For the
AT-8516F/SC,
AT-8524M, and
AT-8524POE
This section describes how to install an optional expansion or stacking
module in the switch.
Note
The modules can be hot-swapped; you do not have to power off a
switch to install these options.
To install a module, follow these steps:
1. Unpack the module from its shipping container and store the
packaging material in a safe location.
Note
You must use the original shipping material if you need to return
the module to Allied Telesyn.
Warning
An expansion or stacking module can be damaged by static
electricity. Be sure to observe all standard electrostatic discharge
(ESD) precautions, such as wearing an antistatic wrist strap, to avoid
damaging the module.
2. Refer to the module’s installation guide for a list of the items
included with the option. If any item is missing or damaged,
contact your Allied Telesyn sales representative for assistance.
3. Face the front panel of the switch and locate the expansion slots
(left side of switch).
4. To remove an expansion slot faceplate, use a Phillips screwdriver to
carefully loosen the installation screws found on the left and right
sides of the faceplate, as shown in Figure 13.
