AT-S63 Management Software Command Line Interface User’s Guide
Section VII: Internet Protocol Routing 605
SHOW IP RIP INTERFACE
Syntax
show ip rip interface[= interface ]
Parameters
interface Specifies the interface name. An interface name
consists of “VLAN” followed by the ID (VID) or name
of the VLAN and an interface number, separated by a
dash (e.g., vlan4-0). If no interface value is specified,
the switch displays all the interfaces where the routing
protocol has been added. For background
information, refer to “Interface Names” on page 552.
Description
This command lists the routing interfaces where RIP has been assigned
and the RIP settings. An example of the information displayed by this
command is shown in Figure 51.
Figure 51. SHOW IP RIP Command
The columns in the display are described here:
ˆ Interface - An interface name consisting of a VLAN’s identification
(VID) number and interface number. For background information, refer
to “Interface Names” on page 552.
ˆ Send - The version of RIP packets sent by the interface. Possible
settings are:
– RIP1: version 1 packets
– RIP2: version 2 packets
ˆ Receive - The version of RIP packets the interface will accept.
Possible settings are:
– RIP1: version 1 packets
– RIP2: version 2 packets
-----------------------------------------------------------
Interface
Send Receive Auth Password
-----------------------------------------------------------
vlan2-0
RIP2 BOTH PASS ********
vlan5-0 RIP1 BOTH NONE NOT SET
vlan8-0 RIP2 BOTH PASS ********
vlan8-1 RIP2 BOTH PASS ********
