Overview
3
NXR-ZGW/-ZRP
NXR-ZRP Specifications
The following table outlines the specifications for the NXR-ZRP.
NXR-ZRP (FG5791-02) Specifications
Dimensions (HWD):
• 906 x 2.500 x 3.424 (23.01 mm x 63.50 mm x 86.96 mm) depth does not
include antenna
Weight:
• 0.25 lbs (113.39g)
Power:
10.5 - 18 VDC; 13.5 (nominal operation voltage)
Memory:
• 16 Mbytes of Flash
• 1 Megabit external memory
Radio Specifications:
Frequency
IEEE 802.15.4
Operating channels
• 11 - 26
Modulation technique
• DSS
Output power
• Region/country specific
Coverage area
165 feet (502.m)
Firmware/Software
Specifications:
Communications
The NXR-ZRP communicates with a Netlinx master via a NXR-ZGW. The
NXR-ZGW communicates with a Netlinx master over TCP/IP encapsulating the
ICSP protocol via a physical Ethernet connection. The ICSP device number
can be set via the browser-based management system.
Front Components:
LEDs
• PWR/STATUS - A green LED that blinks to indicate the device is
programmed and communicating properly. Power ON, but no master
connection, is indicated with a solid light; Power OFF is indicated with no
light.
• ICSP - The LED is solid when ICSP connection is in place with the NetLinx
master.
• RF - The LED is solid when end devices are connected; end devices not
connected is indicated with no LED light; the LED blinks to indicate activity.
Antenna Mount
A reverse SMA connection that supports a 2.4GHz antenna.
Reset Button
Press and hold for approximately 10 seconds to return the NXR-ZRP to factory
default settings.
Rear Components:
Power connector
• 2-pin 3.5mm Phoenix connector
Certifications:
• FCC ID: CWU-ZRD
• IC ID: 5088A-ZRD
• CE
• IEC-60590
• TELEC
Operating/Storage
Environments:
• Operating Temperature: -30°C (-22°F) to 70°C (158°F)
• Relative Humidity: 5% to 85% non-condensing; intended for indoor use only
Included Accessories:
• 2.4GHZ, MONO, RSMA, 3.5IN, 2.0DBI Antenna (70-0012-SA)
• Rubber feet
• Velcro mounting strip
• Power Supply (24-5791-SA)
