NXR-ZGW Browser-based Configuration Manager Pages
16 NXR-ZGW/-ZRP
Checking the firmware version
The firmware version is listed on the Summary of Gateway Settings page of the NXR-ZGW Browser-
based Configuration Manager.
Checking the ZigBee firmware version
The ZigBee firmware version is listed on the Summary of Gateway Settings page of the NXR-ZGW
Browser-based Configuration Manager.
Determining the IP settings of the NXR-ZGW
1. Browse to the Summary of Gateway Settings page of the NXR-ZGW Browser-based Configuration
Manager.
2. The IP settings are listed in the aptly-named section IP Settings.
Finding the ICSP device number of this unit
1. Browse to the Summary of Gateway Settings page of the NXR-ZGW Browser-based Configuration
Manager.
2. The ICSP device number is listed under the section System Connection, Device ID.
Determining the PAN settings of the NXR-ZGW
1. Browse to the Summary of Gateway Settings page of the NXR-ZGW Browser-based Configuration
Manager.
2. The PAN settings are listed in the aptly-named section PAN Settings.
Rebooting the Configuration Manager
1. Browse to the Summary of Gateway Settings page of the NXR-ZGW Browser-based Configuration
Manager.
2. Click the Reboot button on the left bottom of the Summary of Gateway Settings page.
Summary Page (Cont.)
Gateway The IP gateway used by this unit.
Device ID The ICSP device number of this unit
Wireless The state (Disabled/Enabled) of the wireless connection.
Channel The channel the ZigBee wireless will use.
Pan ID The ZigBee personal area network ID used.
Access List The current state of the Access List (Disabled/Enabled).
Distribute Password Current mode of ZigBee password distribution (Disabled/Enabled).
