Overview
4 NXR-ZGW/-ZRP
NXR-ZRP (FG5791-02) Specifications (Cont.)
Other AMX Products: • Mio Modero R-3 Remote (FG148-03)
• Mio Modern R-4 Remote (FG148-04)
• NXR-ZGW NetLinx ZigBee Gateway (FG5791-01)
• NXA-WAP 2403A 3 dBI Antenna (FG2255-20)
• NXA-WAP 2405A 5.5 dBI Antenna (FG2255-21)
• NXA-WAP 2413A Mounting Bracket (FG2255-24)
FIG. 2 Front and Rear Components of the NXR-ZRP
PWR
12VDC
RESET ANT
RF
ICSP
PWR/STATUS
(Front)
(Rear)
Reset Button
Antenna Mount
2-pin 3.5mm Phoenix
Connection LEDs
power connector
Connection to the Repeater device from either the NXR-ZGW or the Mio Modero
®
R-
3 or R-4 requires download and installation to the repeater of ZigBee Module
firmware version 1.01.12, available from www.amx.com.
