AMX NetLinx ZigBee Compatible Gateway and Repeater NXR-ZGW/-ZRP - Manual (Page 33)

NXR-ZGW Browser-based Configuration Manager Pages
27 NXR-ZGW/-ZRP
Connection Log
The connection log is a list of all recent ZigBee device activity.
Determining the connection status of a device
1. In the menu on the top of the NXR-ZGW Browser-based Configuration Manager, select Connection
Log under the section Utilities.
2. The connection status of each device is located in the column Connection; the possible values are
either Connected or Disconnected.
Finding a device’s EUI address
1. In the menu on the top of the NXR-ZGW Browser-based Configuration Manager, select Connection
Log under the section Utilities.
2. The EUI address of each device is located in the column EUI-64.
Finding the device’s ICSP number
1. In the menu on the top of the NXR-ZGW Browser-based Configuration Manager, select Connection
Log under the section Utilities.
2. The ICSP number of each device is located in the column Device #.
FIG. 14 Connection Log Page
Connection Log Page
# The device’s NetLinx ID number
Connection Indicates the connection status of the device.
EUI-64 The 64-bit EUI address of the device.
Device # The device's ICSP device number.
Clicking on the EUI-64 number in the Connection Log page will open the device’s
PAN Device Details page (see FIG. 12).
