AT-FS705PD Fast Ethernet Switch Installation Guide
9
Uplink
Figure 4 illustrates multiple AT-FS705PD switches can be interconnected
using uplinks from a centralized backbone Fast Ethernet switch.
Figure 4 Uplink Topology
24VDC 1 2 3 4 5
POE
24VDC 1 2 3 4 5
POE
24VDC 1 2 3 4 5
POE
Link
Mode Link
Mode
100 FULL ACT
MODE COL FAULT MASTER
PWR
AT-8024GB 10Base-T/ 100Base-TX Fast Ethernet Switch
RS-232 TERMINAL P ORT
LINK
MODE
PORT A
LINK
MODE
PORT B CLASS 1 LASER PRODUCT
DO NOT STARE INTO BEAM
10/100 Mbps
10/100 Mbps
(receiving/transmitting
both power and data)
Power Sourcing Equipment (PSE)
AT-FS705PD
AT-FS705PD
AT-FS705PD
