AT-FS705PD Fast Ethernet Switch Installation Guide
3
Status LEDs
Table 1 defines the LEDs for the switch.
Table 1 Status LEDs
Table 2 defines the LEDs for the power of the switch.
Table 2 Power Status LEDs
LED Color Description
LINK/ACT Green
OFF
Blinking
A valid link has been established on the port.
No link has been established on the port.
Data is being received or transmitted on the port.
100M Green
OFF
The port is operating at 100 Mbps.
The port is operating at 10 Mbps.
FDX Green
OFF
The port is operating in full-duplex mode.
The port is operating in half-duplex mode.
PWR LED Color Description
POE Green
OFF/
Blinking
The switch is powered with the Power-Over-Ethernet feature via
Port 5.
The switch is not powered with the Power-Over-Ethernet feature
via Port 5.
WALL Green
OFF
The switch is powered with a wall adapter.
The switch is not powered with a wall adapter.
