Overview
8
Network Topologies
The AT-FS705PD switch can be used in different topologies such as
standalone and uplink. Each topology is describe below.
Standalone
A standalone topology uses one switch to connect the end-nodes. Figure 3
illustrates a standalone topology that uses an AT-FS705PD switch to connect
several workstations and a server.
Figure 3 Standalone Topology
24V D C 1 2 3 4 5
POE
Link
Mode
Link
Mode
100 FULL
ACT
MODE
COL
FAULT
MASTER
PWR
AT-8024GB 10Base-T / 100Base-TX Fast Ethernet Swi tch
RS-232 TERMINAL POR T
LINK
MODE
PORT A
LINK
MODE
PORT B CLASS 1 LASER PRODUCT
DO NOT STARE INTO BEAM
Power Sourcing Equipment (PSE)
AT-FS705PD
10/100 Mbps
10/100 Mbps
(receiving/transmitting
both power and data)
