6.17 AT-RG600 Series
Topics:
VLAN Information Window
Add/Modify VLAN Dialogs
Notes
•
•
•
6.17.1 VLAN Information Window
The VLAN Information Window displays the following attributes for each VLAN
definition:
Column Name Description
Name This is the name of the VLAN.
Identifier This is the unique identifier of the VLAN.
Tagged Ports
This is a list of the tagged member ports of the
VLAN.
Untagged Ports
This is a list of the untagged member ports of
the VLAN.
Priority This indicates the 802.1p Priority.
Status
This indicates the status of the VLAN.
ƒ static
6.17.2 Add/Modify VLAN Dialogs
The Add/Modify VLAN Dialogs have the following Input Fields:
Input Field Valid Values Length
Name (cannot be modified)
- Alphanumeric characters
- Underscore ("_")
- Dash ("-")
Note - VLAN names cannot start with a digit
and cannot contain period '.' or slash '/'
symbols.
1 - 15
characters
Identifier (cannot be
modified)
•
• 1 - 512 (AT-RG656BD)
1 - 4094 (AT-RG613TX / AT-RG613SH /
AT-RG644B / AT-RG634A / AT-
RG613LH / AT-RG613BD)
-
