6.8 AT-8500 Series
Topics:
•
•
•
6.8.1 VLAN Information Window
The VLAN Information Window displays the following attributes for each VLAN definition:
Column Name
Description
Name
This is the name of the VLAN.
Identifier
This is the unique identifier of the VLAN.
Tagged Ports
This is a list of the tagged member ports of the VLAN.
Untagged Ports
This is a list of the untagged member ports of the VLAN.
Status
This indicates the status of the VLAN.
•
active
•
not in service
•
not ready
•
create and go
•
create and wait
•
destroy
6.8.2 Add/Modify VLAN Dialogs
The Add/Modify VLAN Dialogs have the following Input Fields:
Input Field
Valid Values
Length
Name
- Alphanumeric characters
- Underscore ("_")
- Dash ("-")
Note
- VLAN names must contain at least one (1)
alphabet character.
1 - 20 characters
Identifier (cannot
be modified)
1 - 4094
-
