6.13 AT-9400 Series
Topics:
VLAN Information Window •
Add/Modify VLAN Dialogs •
Notes •
6.13.1 VLAN Information Window
The VLAN Information Window displays the following attributes for each VLAN definition:
Column Name Description
Name This is the name of the VLAN.
Identifier This is the unique identifier of the VLAN.
Tagged Ports This is a list of the tagged member ports of the VLAN.
Untagged Ports
This is a list of the untagged member ports of the
VLAN.
Status
This indicates the status of the VLAN.
•
•
•
• idle
operational
under-construction
not-operational
6.13.2 Add/Modify VLAN Dialogs
The Add/Modify VLAN Dialogs have the following Input Fields:
Input Field Valid Values Length
Name
- Alphanumeric characters
- Underscore ("_")
- Dash ("-")
Note - VLAN names must contain at least
one (1) alphabet character.
1 - 20 characters
Identifier (cannot be
modified)
1 - 4094 -
AlliedView™-EMS 3.10 VLAN Manager User’s Guide Page 59 of 71
