AT-S63 Management Software Menus User’s Guide
Section VI: Virtual LANs 529
An example of the Show VLANs window is shown in Figure 196.
Figure 196. Show VLANs Menu
Section 1 lists all the tagged and untagged ports in the protected ports
VLAN. Section 2 lists the groups in the VLAN, starting with the uplink
port(s). The groups are listed by group number followed by the port
numbers. For example, in Figure 196 the uplink port for the VLAN is
port 24 and Group 1 consists of ports 8 and 11.
Allied Telesis AT-9424T/SP - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Show VLANs
VID VLAN Name VLAN Type Protocol Untagged (U) / Tagged (T)
------------------------------------------------------------------
3
Production Protected U: 8-19
Protected T: 24
Group Ports
---------------------------------------------
Uplink
24
1 8-11
2 12-15
3 16
4 17
5 18-19
N - Next Page
U - Update Display
R - Return to Previous Menu
Enter your selection?
Section 1
Section 2
