Configuring Port Mirroring
To configure port mirroring, perform the following procedure:
1. From the main menu, select Port Mirroring.
The Port Configuration page is shown in Figure 15.
Figure 15. Port Configuration Page
2. From the Target Port list, select the target port:
This is the port where you will connect the network analyzer and the
port to which traffic is mirrored.
3. From the Status list, choose Enabled.
4. In the table, choose one of the following options for the mirrored
(source) port:
RX
Mirrors only received traffic.
TX
Mirrors only transmitted traffic.
Both
Mirrors both received and transmitted traffic.
5. Click Apply to implement your changes.
