AlliedView™-EMS 4.0.2 VLAN MANAGER USER’S GUIDE Page 65 of 77
6.15 AT-9900s Series
Topics:
•
VLAN Information Window
•
Add/Modify VLAN Dialogs
•
Notes
6.15.1 VLAN Information Window
The VLAN Information Window displays the following attributes for each VLAN definition:
Column Name Description
Name This is the name of the VLAN.
Identifier This is the unique identifier of the VLAN.
Operation Mode This indicates the operation mode of the VLAN.
Type
This indicates the type of the VLAN.
•
Port-based
•
Multiple Type
Tagged Ports This is a list of the tagged member ports of the VLAN.
Untagged Ports This is a list of the untagged member ports of the VLAN.
Uplink Port This identifies the uplink port of the VLAN.
Private Ports This is a list of the private ports of the VLAN.
Core Ports This is a list of the core ports of the VLAN.
Customer Ports This is a list of the customer ports of the VLAN.
Status
This indicates the status of the VLAN.
•
dynamic
•
static
6.15.2 Add/Modify VLAN Dialogs
The Add/Modify VLAN Dialogs have the following Input Fields:
