AlliedView™-EMS 4.0.2 VLAN MANAGER USER’S GUIDE Page 43 of 77
6.5 AT-8300GB Series
Topics:
•
VLAN Information Window
•
Add/Modify VLAN Dialogs
•
Notes
6.5.1 VLAN Information Window
The VLAN Information Window displays the following attributes for each VLAN definition:
Column Name Description
Name This is the name of the VLAN.
Identifier This is the unique identifier of the VLAN.
- Tagged Ports This is a list of the tagged member ports of the VLAN that
belong to a specific module on the stack.
- Untagged
Ports
This is a list of the untagged member ports of the VLAN that
belong to a specific module on the stack.
Status
This indicates the status of the VLAN.
•
idle
•
operational
•
under-construction
•
not-operational
6.5.2 Add/Modify VLAN Dialogs
The Add/Modify VLAN Dialogs display the following Input Fields:
Input Field Valid Values Length
Name
- Alphanumeric characters
- Underscore ("_")
- Dash ("-")
0 - 32 characters
Identifier 1 - 4094 -
6.5.3 Notes
•
Ports in the Default VLAN cannot be changed from untagged to tagged.
•
VLAN definitions that only contain tagged ports cannot be deleted.
•
The Retry Timeout value may have to be increased depending on the number of
devices on the stack; otherwise, Add VLAN and Modify VLAN operations may fail.
6 Device Support
