AlliedView™-EMS 4.0.2 VLAN MANAGER USER’S GUIDE Page 56 of 77
6.11 AT-9000/24 and AT-9410GB
Topics:
•
VLAN Information Window
•
Add/Modify VLAN Dialogs
•
Notes
6.11.1 VLAN Information Window
The VLAN Information Window displays the following attributes for each VLAN definition:
Column Name Description
Name This is the name of the VLAN.
Identifier This is the unique identifier of the VLAN.
Tagged Ports This is a list of the tagged member ports of the VLAN.
Untagged Ports This is a list of the untagged member ports of the VLAN.
Status
This indicates the status of the VLAN.
•
idle
•
operational
•
under-construction
•
not-operational
6.11.2 Add/Modify VLAN Dialogs
The Add/Modify VLAN Dialogs display the following Input Fields:
Input Field Valid Values Length
Name
- Alphanumeric characters
- Underscore ("_")
- Dash ("-")
0 - 32 characters
Identifier 1 - 4094 -
6.11.3 Notes
•
The current firmware version does not allow VLAN definitions to be created
without a VLAN name. As a result, the Add VLAN, Modify VLAN and Import VLAN
operations will fail when the VLAN Name field is left blank.
•
Ports in the Default VLAN cannot be changed from untagged to tagged.
•
VLAN definitions that only contain tagged ports cannot be deleted.
