AT-GS950/16 and AT-GS950/24 Gigabit Ethernet Smart Switches Installation Guide

31

Installing the Switch on a Desktop

You can install the AT-GS950/16 and AT-GS950/24 Gigabit Ethernet
Smart Switches on a desktop or in a standard 19-inch equipment rack. To
install the switch in a rack, refer to “Installing the Switch in an Equipment
Rack” on page 32.

To place the switch on a desktop, perform the following procedure:

1. Remove all equipment from the package and store the packaging

material in a safe place.

2. Turn the switch over and attach the four rubber feet to the bottom of

the switch as shown in Figure 6.

Figure 6. Attaching the Rubber Feet

3. Turn the switch over again and place it on a flat, secure surface (such

as a desk or table) leaving ample space around the unit for ventilation.

1299

LINK/AC

T

SPEED

LINK/AC

T

SPEED

POWER

15

16

LINK/AC

T

1

3

5

7

9

11

13

15

2

4

6

8

10

12

14

16

AT-GS950/16

16-Por

t 10/100/1000Mbps + 2 SFP Combo WebSmar

t Switch
