Chapter 1: Overview
22
Network Topologies
This section illustrates two network topologies of the AT-GS950/16 and
AT-GS950/24 Layer 2 Gigabit Ethernet Switches: a power workgroup and
collapsed backbone.
Power
Workgroup
Topology
The topology shown in Figure 4 is commonly referred to as a power
workgroup topology. This topology provides the best in performance and
reliability because each end node is connected directly to the AT-GS950/
24 Switch with a dedicated network link.
Figure 4. Power Workgroup Topology
Legend
100 Mbps
AT-GS950/24 Switch
1000 Mbps
1296
1
3
5
7
9
11
13
15
17
19
21
23
POWER
2
4
6
8
10
12
14
16
18
20
22
24
23
24
LINK/ACT
LINK/ACT
SPEED
LINK/ACT
SPEED
AT-GS950/24
24-Port 10/100/1000Mbps + 2 SFP Combo WebSmart Switch
