Chapter 1: Overview

20

Table 4 describes the LEDs for the SFP ports.

LINK/ACT Off

The port has not established a link with an
end node.

Blinking
Green

The port is transmitting or receiving data.

Green

A valid link has been established on the port.

Table 4. SFP Port LEDs

LED

State

Description

LINK/ACT Off

The port has not established a link with an
end node.

Blinking
Green

The port is transmitting or receiving data.

Green

A valid link has been established on the port.

Table 3. 10/100/1000Base-T Port LEDs (Continued)

LED

State

Description
