Allied Telesis AT-2711 Series Adapters - Manual (Page 116)

Modifying Advanced Properties
116
Wake on Pattern Match
The Wake on Pattern Match feature enables the network adapter to wake
up from a low-power mode when the packet matches the wake patterns
specified in the operating system.
To enable of disable the Wake on Pattern Match feature, do the following:
1. Access the Advanced Properties.
See “Accessing Advanced Properties” on page 76.
2. Select Wake on Pattern Match in the Property box.
The Wake on Pattern Match page is displayed as shown in Figure 63.
Figure 65. Wake on Pattern Match Page
3. Select one of the following options:
 Enable — The adapter wakes up from a low-power mode when
receiving a packet that matches one of the patterns specified in the
operating system.
 Disable — The adapter stays in a low-power mode.
4. Click OK.
