Ac power led, Figure 8: ac power led, Table 7: ac power led description – Allied Telesis AT-DC2552XS User Manual
Page 28
Chapter 1: Overview
28
AC Power LED
Each AT-PWR06 power supply module has a AC power (AC OK) LED.
This LED is shown in Figure 8.
Figure 8. AC Power LED
The AC Power LED is described in Table 7
Table 7. AC Power LED Description
Location
LED
State
Description
Power Supply
Module Panel
AC OK
Solid Green
AC power is supplied to power supply.
Off
No AC power is supplied to power supply.
