Hardware description, 1 front panel, 2 top view – Allied Telesis AT-IMC1000T/SFP User Manual
Page 8: Front panel top view
Hardware Description
Front Panel
8
AT-IMC1000T/SFP Industrial Gigabit PoE+ Media Converter User Manual
2. Hardware Description
In this paragraph, we will introduce the Industrial Media Converter’s hardware spec, port, cabling information, and
wiring installation.
2.1 Front Panel
The Front Panel of the AT-IMC1000T/SFP Industrial Media Converter is shown as below.
FIGURE 2-1 Front Panel of the Industrial Media Converter
2.2 Top View
The top panel of the Industrial Media Converter is equipped one terminal block connector of two DC power inputs.
Warning: Please connect Ground Wire to Ground Screw located near to the power socket.
