Overview Features
6 AT-IMC1000T/SFP Gigabit Ethernet Industrial Media Converter
1.1.7 Easy Troubleshooting
LED indicators make troubleshooting quick and easy. The 10/100/1000 Base-TX port (P1) has 2 LEDs that display
the link status, network activity and the port speed. Also the three power indicators P1, P2 and Fault can help you
diagnose power issues immediately.
1.2 Features
Table 1-1: Unit Features
Standard IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3ab 1000Base-T
IEEE 802.3x Flow Control and Back pressure
IEEE 802.3z 1000BaseSX/LX standards
LED Indicators Per unit: Power1 (Green), Power2 (Green), Fault (Red)
Fiber: Link/Active (Green)
TX: Link/Active (Green), 1000M (Amber)
Connector Fiber: 1 G Duplex LC SFP bay slot x 1
RJ-45 (10/100/1000Mbps) Socket x 1
Fiber Parameters Fiber parameters and distances will depend upon the used SFP
module.
Please refer to SFP module documentation
Link Lose Forward TX -> SFP: If TX port link down, the media converter will force
SFP port to link down
SFP -> TX: If SFP port link down, the media converter will force
TX port to link down
Switch Architecture Store and Forward
Power Input 12~48VDC, redundant power with polarity reverse protect func-
tion and removable terminal block
Power Consumption 5.28 Watts (max.)
Operating Tempera-
ture Wide Operating Temperature: -40°C to 75°C
Operating Humidity 5% to 95%
Storage Environment -40°C to 85°C
Dimensions Metal case. IP-30,
30mm (W) x 140mm (H) x 95mm (D)
Installation DIN-Rail and Wall-mount design
