Page 4-4
Troubleshooting
❏ Ping-Pong Test — verifies communication with another
Macintosh on the network.
❏ Bandwidth Utilization Test — calculates the total band-
width utilization of the network.
13 Click all three checkboxes to select the Loopback Test , the
Ping-Pong Test , and the Bandwidth Utilization Test .
14 Click the highlighted slot number where the Asanté 10NIC-
PCI adapter is installed.
15 Click the TEST button to start the test sequence.
If the Bandwidth Utilization Test is selected, press any key
to stop packet collection.
When the tests finish, the test results are displayed in the
Troubleshooter window.
16 Verify the results to make sure that all tests passed.
If a test fails, check that the adapter is seated properly in a
PCI slot or try installing the adapter in a different PCI slot
and run the tests again. Make sure your computers’s power
cord is first unplugged before wiggling or removing any
adapter cards!
17 Click the QUIT button in the Troubleshooter window or
select Quit from the menu bar.
18 Return your adapter card to normal by opening the Apple
Menu and selecting Control Panels, then AppleTalk.
The AppleTalk control panel appears.
19 Click the Connect Via: drop-down menu.
20 Select the Ethernet slot number where the adapter is
installed.
21 Close the AppleTalk control panel by clicking on the close
box.
A dialog box appears asking whether you want to save
changes.
22 Click Save.
23 Check the chooser to confirm you can see zones, printers and/or
servers on the network.
