Page 36
Page 4-2
Troubleshooting
Link Integrity LED
The green Link Integrity (LI) LED indicates a valid connection to the net-
work. If link integrity is not detected, there is a link failure and the LI LED
will be off. The transmit and receive functions of the adapter also will be dis-
abled.
Data Traffic LED
The amber Data Traffic (TX) LED indicates the activity (transmit data) status
of the adapter controller board. The LED should blink when data packets are
being transmitted over the cable.
State
Description
On
• Normal data packets are received or
link integrity is detected
Off
• No unshielded twisted-pair cable is
connected
• No power source to hub
• Unshielded twisted-pair cable is
faulty
• Unshielded twisted-pair wire
exceeds the recommended length
State
Description
Blinking
• Data packets being transmitted
Off
• Power off
• No data packets being transmitted
