Page 88
78
Chapter 3
Removing the Heatsink Module
NOTE: There are two version of heatsink module. For this section, we are going to use the discrete model.
The UMA version looks like the picture below:
1.
See “Removing the Battery Pack” on page 54.
2.
See “Removing the Lower Cover” on page 56.
3.
Disconnect the heatsink connector from the main board.
