Page 74
64
Chapter 3
NOTE: When attaching the antenna back to the WLAN board, make sure the cable are arranged properly.
Removing the Hard Disk Drive Module 1
1.
See “Removing the Battery Pack” on page 54.
2.
See “Removing the Lower Cover” on page 56.
3.
Remove the one screw (B) securing the hard disk drive module.
Step
Size (Quantity)
Color
Torque
1
M2 x L4 (1)
Silver
1.6 kgf-cm
