5. Lift the hard disk drive module and remove it from the hard disk drive bay.
NOTE: To prevent damage to device, avoid pressing down on it or placing heavy objects on top of it.
6. Follow the step 6 of “Removing the Hard Disk Drive Module 1” on page 64 to remove the hard disk from
the bracket.
Removing the Optical Drive Module
1. See “Removing the Battery Pack” on page 54.
2. See “Removing the Lower Cover” on page 56.
3. Remove the one screw (B) securing the optical drive module to the system.
Step Size (Quantity) Color Torque
1 M2 x L4 (1) Silver 1.6 kgf-cm
